Mechanical & Operational Design
- Thermally stable source
- chamber improves long-term signal consistency.
- Robust plasma torch assembly
designed for long service life in heavy-use labs. - Modular internal layout
simplifies routine maintenance and service. - System is suitable for laboratories
and field-level testing institutes.
Key Strengths
|
Advantage |
Meaning in Real Work |
|
High sensitivity + wide mass range |
Detects heavy metals, rare earths, trace
contaminants |
|
Automated workflow |
Reduced operator expertise required |
|
Fast cycle times |
Ideal for high-throughput labs |
|
Stable performance |
Lower downtime and maintenance cost |
|
Industrial-grade build |
Designed for 24/7 process labs, not just
research environments |
| Feature | Description |
|---|---|
| Method | ICP-MS (Inductively Coupled Plasma Mass Spectrometry) |
| Spectral Range | 2 to 255 amu, covering major, minor, and trace elements |
| Mass Analyzer | Quadrupole mass spectrometer |
| Resolution | 0.8 amu, allowing accurate separation of closely-spaced masses |
| Sensitivity | High — capable of ppb to ppt level detection |
| Throughput | Typical analysis completed in < 5 minutes |
| Power | 1000 to 1600 W RF power, adjustable for different matrices |
| Sample Handling | Automated high-throughput introduction system |
The system supports multi-element detection in a single run, essential for environmental surveys, geological screening, alloy verification, and contamination monitoring.
| Sector | Use Cases |
|---|---|
| Environmental Monitoring | Water quality, soil contamination, heavy metal screening |
| Geology & Mining | Rare earth content, ore characterization, elemental speciation |
| Materials Science / Metallurgy | Alloy composition, impurity detection, corrosion analysis |
| Food & Agriculture | Trace metal contamination, nutrition mineral profiling |
| Energy & Petrochemical | Catalyst monitoring, wastewater analysis, fuel additive studies |
| Pharmaceutical & Biotech | Elemental impurities (ICH Q3D compliance) |
The PlasmaMS 300 includes a modern, intuitive software suite designed for laboratory quality systems:
- Automated calibration and drift correction
- Built-in quality control tracking (blanks, standards, control charts)
- Reporting compliant with industrial and regulatory standards
- Data visualization tools for spectra, isotope ratios, and concentration trends
This reduces operator workload and supports continuous, high-volume operation.
ISO9001, ISO/IEC 17025, NADCAP, Rolls-Royce approval, and others.
